1. Product Overview

MAGEON is a professional manufacturer specializing in the development and manufacturing of steel track undercarriages, covering 1 to 60-ton crawler machinery. With mature production processes and customization capabilities, the company provides full-process services from solution design and component matching to manufacturing and inspection, according to machine requirements. Products are widely used in drilling rigs, crushers, excavators, piling machines, coal mining equipment, mining equipment, and other fields. OEM/ODM customization is available.

2. Core Advantages

1-60 Ton Full Coverage — Customized as Needed
MAGEON steel track undercarriages cover a load capacity of 1 to 60 tons. Customized designs are available according to machine weight, mounting dimensions, travel speed, and working conditions, meeting the matching requirements of different crawler machinery.

Complete Assembly — One-Stop Solution
Complete undercarriage assemblies are provided, including steel tracks, track links, track rollers, front idlers, drive sprockets, hydraulic motors, travel gearboxes, crossbeams, and other components, ensuring system compatibility and reliability while reducing customer procurement and assembly processes.

Multiple Drive Options — Flexible Adaptation
Hydraulic drive, electric drive, and mechanical drive configurations are available, matched to the customer's power system and travel requirements, suitable for crawler equipment under different working conditions.

High-Strength Steel Structure — Heavy-Duty Load Capacity
The chassis beam is made of Q345B high-strength steel. The overall structure is optimized for excellent load capacity and torsional rigidity, capable of supporting machine weights from 1 to 60 tons.

OEM/ODM Customization — Manufactured to Drawings
Customers are welcome to provide undercarriage drawings or technical specifications. MAGEON can customize designs and manufacturing according to mounting dimensions, load capacity, climbing requirements, slewing requirements, etc. Drawing-based and sample-based processing is supported.

3. Undercarriage Structure

4. Application Scenarios

The product is widely used in the following fields:

Drilling Rigs: Anchor rigs, water-well rigs, core drilling rigs, jet grouting rigs, down-the-hole drills, crawler hydraulic drilling rigs, pipe roof rigs, and other trenchless equipment.

Construction Machinery: Mini excavators, mini piling machines, exploration machines, aerial work platforms, small loading equipment.

Coal Mining: Grilled slag machines, tunnel drilling rigs, hydraulic drilling rigs, rock loading machines.

Mining: Mobile crushers, heading machines, transport equipment.

Others: Construction robots, lifting equipment, forestry machinery, agricultural machinery, etc.

5. Customization Service

MAGEON provides comprehensive customization services according to customer equipment requirements, including:

• Load Capacity: Customizable from 1 to 60 tons

• Track Width: 200–500 mm available

• Undercarriage Dimensions: Customized to machine mounting requirements

• Drive Type: Hydraulic, electric, or mechanical options

• Travel Gearbox: Single-speed or dual-speed available

• Slewing System: Can be integrated with slewing bearing for 360° rotation

• Color: Black or custom color

• Drawing-Based Manufacturing: Customization based on customer drawings

6. Development Process

7. FAQ

Q1: What is the load capacity range of MAGEON's track undercarriages?
A: The load capacity ranges from 1 to 60 tons, customizable according to machine weight.

Q2: Is OEM/ODM customization available?
A: Yes. MAGEON provides OEM/ODM customization services. Customers are welcome to provide undercarriage drawings or technical specifications for customized design and manufacturing based on mounting dimensions, load capacity, and climbing requirements.

Q3: What components are included in the undercarriage?
A: A complete undercarriage assembly is provided, including steel tracks, track links, track rollers, front idlers, drive sprockets, hydraulic motors, travel gearboxes, and crossbeams. Slewing bearings are optional.

Q4: What drive types are supported?
A: Hydraulic drive, electric drive, and mechanical drive are supported, matched to the customer's machine power system.

Q5: What is the warranty period?
A: 1 year or 1000 hours, whichever comes first.

Q6: What is the delivery time?
A: Estimated 20 days for 1 set, 30 days for 2-3 sets, and to be negotiated for more than 3 sets.

Q7: What are the packaging and shipping methods?
A: Wooden pallet or steel pallet packaging is used. Ocean shipping, air freight, and land transportation are supported and can be arranged according to customer requirements.
