1. Product Overview

The MAGEON 3-15 ton rubber-padded steel track undercarriage is designed for crawler machinery that requires stable travel on multiple surface conditions. The undercarriage uses steel tracks as the running base, with rubber pads fitted to the track shoes, retaining the high load capacity and traction of steel tracks while effectively reducing damage to asphalt and concrete surfaces. Equipped with a hydraulic drive system and a compact structure, it is suitable for drilling rigs, mobile crushers, mini excavators, piling machines, and other equipment. Customization is available for dimensions, load capacity, and drive configuration according to machine requirements.

2. Design Highlights

Steel Tracks + Rubber Pads — Load Capacity and Surface Protection
Steel tracks serve as the load-bearing base, with rubber pads added to the track shoes. This design is suitable for applications requiring frequent relocation or travel on paved surfaces. The rubber pads effectively reduce scraping and indentation on the road surface while maintaining the high traction and wear resistance of steel tracks.

Hydraulic Drive — Stable and Reliable Travel Power
The undercarriage uses a hydraulic drive system with a travelling speed of 2-4 km/h. It can be matched to the customer's hydraulic system parameters to ensure smooth travel and controllable start/stop.

Compact Structure — Suitable for Various Small and Medium Equipment
With undercarriage dimensions of 2250×300×535 mm (L×W×H), the compact structure is suitable for space-constrained operations. It can be matched with anchor rigs, water-well rigs, core drilling rigs, mini excavators, mobile crushers, and other equipment.

Modular Customization — Flexible Configuration per Machine Requirements
Adopting a modular design, the track width, undercarriage length, track gauge, drive type, and rubber pad specifications can be adjusted according to machine weight, mounting dimensions, travel speed requirements, and working conditions.

3. Undercarriage Structure

4. Application Scenarios

The product is widely used in the following fields:

Drilling Rigs: Anchor rigs, water-well rigs, core drilling rigs, jet grouting rigs, down-the-hole drills, crawler hydraulic drilling rigs, pipe roof rigs, and other trenchless equipment.

Construction Machinery: Mini excavators, mini piling machines, exploration machines, aerial work platforms, small loading equipment.

Coal Mining: Grilled slag machines, tunnel drilling rigs, hydraulic drilling rigs, rock loading machines.

Mining: Mobile crushers, heading machines, transport equipment.

Others: Construction robots, forestry machinery, agricultural machinery, etc.

5. Customization Service

MAGEON provides comprehensive customization services according to customer equipment requirements, including:

• Load Capacity: Customizable from 3 to 15 tons

• Undercarriage Dimensions: Customized to machine mounting requirements

• Track Width: Adjustable

• Rubber Pad Specifications: Selected according to working conditions and surface protection requirements

• Drive Type: Hydraulic drive, matched to customer hydraulic system parameters

• Color: Black or custom color

6. Development Process

7. FAQ

Q1: What is the load capacity of this undercarriage?
A: The load capacity ranges from 3 to 15 tons, customizable according to machine weight.

Q2: What is the function of the rubber pads?
A: The rubber pads are fitted to the steel track shoes to protect asphalt and concrete surfaces, reducing scraping and indentation during travel while maintaining the traction performance of the steel tracks.

Q3: What is the travelling speed?
A: The travelling speed is 2-4 km/h, adjustable upon request.

Q4: What equipment is it suitable for?
A: It is suitable for anchor rigs, water-well rigs, core drilling rigs, mini excavators, mobile crushers, mini piling machines, aerial work platforms, and other crawler machinery.

Q5: Can it be customized according to drawings?
A: Yes. MAGEON can customize designs based on customer-provided mounting dimensions, load capacity, and working condition requirements.

Q6: What are the warranty and delivery times?
A: The warranty is 1 year or 1000 hours, whichever comes first. Estimated delivery is 20 days for 1 set, 30 days for 2-3 sets, and to be negotiated for more than 3 sets.
